SPECIFICATIONS

Units

C6140

C6240

Max Swing diameter over bed

mm

400

Max Swing diameter over cross slide

mm

230

Max Swing diameter over gap

mm

560

Distance between centers

mm

750/1000/1500/2000/3000

Spindle bore diameter

mm

52（Opt.80）

Spindle bore taper

-

MT6 （Opt. Metric 1:20）

Spindle speed range

rpm

40-1400

Spindle speed steps

-

9

Cross slide travel

mm

200

Top tool post travel

mm

95

Tool size

mm

20*20

Longitudinal feeds range

mm/r

0.0832-4.6569

Cross feeds range

mm/r

0.048-2.688

Kinds of metric threads

kinds

19

Range of metric threads

mm

0.25-14

Kinds of inch threads

kinds

28

Range of inch threads

T.P.I.

2-40

Kinds of threads module

kinds

17

Range of threads module

M.P.

0.25-3.5

Tailstock quill diameter

mm

65

Tailstock quill taper

-

MT4

Tailstock quill travel

mm

130

Main motor power

kw

4

Coolant motor power

kw

0.09

Weight for 750

kg

1220

Weight for 1000

kg

1320

Weight for 1500

kg

1520

Weight for 2000

kg

1720

Weight for 3000

kg

1920

Dimension for 750

mm

2200*1140*1550

Dimension for 1000

mm

2400*1140*1550

Dimension for 1500

mm

2900*1140*1550

Dimension for 2000

mm

3400*1140*1550

Dimension for 3000

mm

4400*1140*1550
