Specifications

C6160

Capacity

Max. Swing over bed

600mm

Max. rotating diameter

400mm

Center distance

750,1000,1500,2000mm

Spindle hole

52mm(82mm)

Spindle

Spindle nose

ISO-C6(C8)

Spindle taper

MT6

Spindle speeds(Number)

40-1400rpm (9 Steps)

Feed

Metric threads range(Kinds)

0.5-14mm (20 Kinds)

Inch threads range(Kinds)

2-40/inch (28 Kinds)

Module threads range(Kinds)

0.25-3.55mπ (11 Kinds)

Compound rest travel

150mm

Cross slide travel

180mm

Cross-section size of tool shank

20×20mm

Tailstock

Dia. of tailstock sleeve

65mm

Taper of tailstock sleeve

MT5

Travel of tailstock sleeve

140mm

Main motor power

7.5KW

Machine size
(L*W*H mm)

Overall dimensions for750mm

2100×1150×1550mm

Overall dimensions for1000mm

2350×1150×1550mm

Overall dimensions for1500mm

2850×1150×1550mm

Overall dimensions for2000mm

3350×1150×1550mm

Weight(kg)

Weight for 750mm

1800kg

Weight for 1000mm

1900kg

Weight for 1500mm

2100kg

Weight for 2000mm

2300kg
