Model No.

C6180/C6280

Max. swing over bed

800mm(31.5")

Max.swing over carriage

560mm(22")

Max. turning dia.

580mm(23")

Max.length of workpiece

1000/1500/2000/3000mm

Max.swing dia.and length in gap

1000mmX240mm

Bed width

510mm

Spindle bore

105mm(D11)

Spindle taper of bore

113mm 1:20

Spindle number of speeds

12 STEPS

Spindle range of speeds

30-1400 rpm

Threads metric pitches

1-14mm/22

Threads imperial pitches

20-2TPI/25

Threads diametral pitches

56-4 DP/24

Threads module pitches

0.5-7mm/18

Range of feeds longitudinal

o.063-2.52mm(0.0023"-0.0937" in/r)

Range of feeds cross

0.027-1.07mm(0.0011"-0.0404" in/r)

Toilstock quill diameter

90mm

Max.traverse of the tailstock quill

150

Quill taper

No.5(morse)

Max.travel of compound rest

145mm

Max.travel of cross slide

405mm

Max.size of tool shank(WXH)

25X25mm

Power of the main motor

7.5KW

Packing size(LXWXH)

(2700/3200/3700/4700)X1180X2200mm

Net weight

3550/3800/4050/4450 kg
