Brand:Mechanics
Product origin:China
Delivery time:2023-03-03
Supply capacity:Mass production
|
Specifications |
C6232 |
C6236 |
C6240 |
C6250 |
C6266 |
||
|
Capacity |
Max. Swing over bed |
320mm |
360mm |
400mm |
500mm |
660mm |
|
|
Max. rotating diameter |
200mm |
200mm |
238mm |
300mm |
470mm |
||
|
Max. swing over gap |
590mm |
590mm |
630mm |
720mm |
880mm |
||
|
Center distance |
750,1000,1500,2000mm |
||||||
|
Spindle hole |
52mm(82mm) |
||||||
|
Spindle |
Spindle nose |
ISO-C6(C8) |
|||||
|
Spindle tap |
MT6 |
||||||
|
Spindle speeds(Number) |
36-1600rpm (12 Steps) |
||||||
|
Feed |
Metric threads range(Kinds) |
0.5-14mm (18 Kinds) |
|||||
|
Inch threads range(Kinds) |
2-40/inch (28 Kinds) |
||||||
|
Module threads range(Kinds) |
0.25-3.5mπ (17 Kinds) |
||||||
|
Compound rest travel |
150mm |
||||||
|
Cross slide travel |
180mm |
||||||
|
Cross-section size of tool shank |
22×22mm2 |
||||||
|
Tailstock |
Dia. of tailstock sleeve |
75mm |
|||||
|
Taper of tailstock sleeve |
MT5 |
||||||
|
Travel of tailstock sleeve |
160mm |
||||||
|
Main motor power |
4KW |
5.5/7.5KW |
7.5KW |
||||
|
Machine size |
Overall dimensions for750mm |
2100×1150×1550mm |
2100×1150×1550mm |
2100×1150×1550mm |
2100×1150×1550mm |
2100×1150×1550mm |
|
|
Overall dimensions for1000mm |
2350×1150×1550mm |
2350×1150×1550mm |
2350×1150×1550mm |
2350×1150×1550mm |
2350×1150×1550mm |
||
|
Overall dimensions for1500mm |
2850×1150×1550mm |
2850×1150×1550mm |
2850×1150×1550mm |
2850×1150×1550mm |
2850×1150×1550mm |
||
|
Overall dimensions for2000mm |
3350×1150×1550mm |
3350×1150×1550mm |
3350×1150×1550mm |
3350×1150×1550mm |
3350×1150×1550mm |
||
|
Weight(kg) |
Weight for 750mm |
1300kg |
1500kg |
1600kg |
1700kg |
1900kg |
|
|
Weight for 1000mm |
1400kg |
1600kg |
1700kg |
1800kg |
2000kg |
||
|
Weight for 1500mm |
1600kg |
1800kg |
1900kg |
2000kg |
2200kg |
||
|
Weight for 2000mm |
1800kg |
2000kg |
2100kg |
2200kg |
2400kg |
||
